HAULINGUNDER 160,000 POUNDS
(Net)
A scientific haul
H
owon earthdoes an extremely
sensitive, 40-footwide
scientificmarvel travel across
two states, uponemountain, on roadshalf
itswidth?Thatwas thequestion facing
PrecisionHeavyHaul, Inc. (PHH) of
Tolleson,AZwhenaccepting the challenge
of transporting a$14million “Prototype
Antenna.”
TheAtacamaLargeMillimeterArray
(ALMA) antenna isused for thedetection
and collectionof dataon radio sources
as theyoperate in the radio frequency
rangeof the electromagnetic spectrum.
Antennas areusually set in an array,which
upgrades theirperformance significantly.
Locations of suchobjects are important
because electromagnetic interferences
from everydayobjects affect data
collection.
This transport originated at theVery
LargeArray site located approximately50
mileswest of Socorro,NM. Itsdestination
wasKitt PeakNationalObservatory, 55
mileswest/southwest ofTucson,AZ, at an
elevationof 7,000 feet. This observatory
gained famebyhosting the first telescope
used to search fornear-earth asteroids,
and calculating theprobabilityof an
impactwithEarth.
PHH’s responsibility, on theotherhand,
>54
PrecisionHeavy Haul
Transporting a $14million ALMA antenna required tedious planning through amountainous
obstacle course.
