Feature
Machine Drive Power
(MDP)
Accelerometer-based
Compaction Measurement
Measurement Depth*
30 - 60 cm (12 - 24 in)
1 - 1.2 m (3.3 - 4 ft)
Correlates well with portable measurement devices
(plate load, LWFD)
Usable with smooth drum, padfoot, or padfoot shell kit
Usable on granular or cohesive material
Measures with vibratory system on or off
Exclusive Cat
®
technology
* Dependent on soil type, moisture and other factors.
If you are measuring compaction with a soil compactor, your
accelerometer-based system might be missing the mark.
Machine Drive Power (MDP)
is a new, innovative soil
compaction measurement technology available only from
Caterpillar.
MDP
measures closer to the depth of the lift with less
variability than accelerometer-based systems, even on
cohesive soils. That gives you confidence that the soil you
are compacting will support the load.
3
3
3
3
3
UNDERNEATH IT ALL
Ask your local Cat dealer about rental and purchase options for your next soil compaction job.
